Uziwave AUDS Series 100w-16555-EN Anti-Drone Power Amplifier

1. Wideband Multi-frequency Operation — Covers three frequency bands (3480–3520 MHz, 3540–3860 MHz, 3700–4000 MHz) with high gain (51±1 dB) and 47±1 dBm output power for flexible deployment.
2. Comprehensive Monitoring & Protection — Features RS485 monitoring with real-time status queries, over-power/over-temperature alarms, and VSWR protection that automatically reduces power to 3W when needed.
Technical Specification:
Product Name:
1. UZI-AUDS-3480~3520M-50W-16550-485
2. UZI-AUDS-3540~3860M-50W-16550-485
3. UZI-AUDS-3700~4000M-50W-16550-485
Cautions
1. Single-tone signal test.
2. The power amplifier has a 485 function.
3. Temperature alarm and protection: Alarm at 85℃ and turn off the power amplifier simultaneously; turn on the power amplifier at 65℃.
4. VSWR (Voltage Standing Wave Ratio) alarm protection: After VSWR alarm, the power amplifier power drops to 3W; when VSWR returns to normal, the power amplifier automatically returns to normal.

Model:
UZI-AUDS-3440~4000M-50W-16550-485
Brand:
UZIWAVE

Quantity:
Availability:





Inquire

Anti-Drone Power Amplifier

Product Description

Items:	Quality Standards
Frequency Range	3480-3520M 3540-3860M 3700-4000M
Max Gain:	51±1dB
Maximum Output Power:	47±1dBm
Maximum Input Level:	+10dBm
Manual Gain Control:	≥25dB
Automatic Gain Control:	≥10dB
Gain Flatness:	ATT10dB： ≤±1dB ATT20dB： ≤±1dB ATT25dB： ≤±1.5dB
In-band Ripple:	≤2.5dB
VSWR	≤1.4
Operating Voltage:	28V
Operating Current:	≤6A
Working Temperature:	-40～+55℃
Over-Temperature Protection:	Alarm and shutdown at +85℃, resume operation at 65℃
Baud Rate:	19200
Connectors:	2 SMA connectors
Chassis Dimension:	1655020
Monitoring	For the wiring diagram of the monitoring port, refer to the outline dimension drawing; RS485 interface communication Settings: switch, gain; Query: module status (including power amplifier status, over-power alarm, over-temperature alarm), power amplifier temperature, power amplifier ATT value, detected forward power; Over-power alarm: alarm when the power exceeds the maximum output power by +2dB; Over-temperature alarm: recommended threshold is +85℃; alarm is triggered when the detected temperature exceeds +85℃, and the power amplifier is turned off simultaneously, then turned on at +65℃; Power amplifier temperature detection: the detection range shall include but not be limited to -25℃～+85℃, with a detection accuracy of ±3℃; Forward power detection: the detection range shall be greater than 20dB, with a detection accuracy of less than ±1dB;
